PS6000-1

PS6000-1 Rack mount UPS RUGGED 1.5kva 1050 watt UPS with shipboard delta Navy standard

• Features: Field shipboard proven, mil 1399, reliable, modular design, mil tested, shock mounted
• Compatible 19 x 5 1/4 x 14.5 with the Navy standard ups used by GBS, Minesweeper MCM, Virginia class subs, GPS,CECOM
•  1500VA UPS 1050watts input and output power, 10 minute battery at 90% load
• - Weight 59 lbs.  tested and approved standalone, WITH 6 MIL CONNECTORS,  no Isolation Transformer
•  Input and output CORCOM EMI/RFI filtering for mil 461
•  Shipboard and/or global GLUPS™ Mil 1399 delta  Power, military ruggedized stainless steel chassis (stainless 304)
•  Mil 5015 MS3102 threaded connectors or 4ea. 5-15 standard outlets ( option to 6ea. 5-15 outlets)
•  New- Now it comes standard with a stainless steel chassis and option to add Isolation transformer later- made in USA stainless steel chassis or  order the PS1503 as a floormount unit (Bulkhead mounting)
• - add Modular design deliverable with/without ISO, dual pole (mil 1399) delta power, modular backplates
• - Intelligent UPS, built-in self test, individual battery test, hot start, relay self test, online voltage adjustments on/the/fly™
• - add  Front or rear mounted Dual pole circuit breaker, on/off reset for shipboard, emergency power off /power on™
• -  add 1 inch for mil ms3102 connectors
• - add Intelligent ruggedized packaging, metal battery tie-down, wire tieback, shock mounted motherboard, color coded wire
• - Coated heat resistant, shock resistant connectors added
• - UPS shutdown software available for UNIX, HP, SUN, SCO, Novell , NT, Apache Web, called Powerchute +
• - 96% efficiency at full load
•   Ruggedized motherboard, single board construction
• - Maximum current 17.5 amps double pole toggle hi-shock input breaker, and output breakers mounted on front or rear
• -add 100 based T Ethernet or fiber interface
• - RS232 communication built in, optional Expansion bus in module for 3 RS232 (three computers),
• - Front Panel bolted down for safety, FAA CFR 49 approved for shipping(non-hazardous), sealed maintenance free batteries
•  optional 140degree F hi-temp 10 year battery life batteries
• - quick release front panel battery removal, online test from front panel
• - Powerful MOV surge and spike firewall protection, isolates racks from spikes up to 400 joules- UL 1778
• - Voltage range from 137 volts to 85 volts 47-63 HZ.  for global usage, without going to battery with sensitivity settings
• - Battery disconnect from back for shipping and emergencies without opening case (extends storage life of batteries)
• - Extensive self maintenance manual, and user manual included
• - Software provided Powerchute +
• - Two year limited warranty
• - Spares stocked by NAVICP
• Thermal dissipation on line fully charged 40w/ 135 BTU Charging 70 watts / 240 BTU
• cage code 0zap8  Thousands installed
•
