PS6000-1
PS6000-1 Rack mount UPS RUGGED 1.5kva 1050 watt UPS with shipboard delta Navy standard
- Features: Field shipboard proven, mil 1399, reliable, modular design, mil tested, shock mounted
- Compatible 19 x 5 1/4 x 14.5 with the Navy standard ups used by GBS, Minesweeper MCM, Virginia class subs, GPS,CECOM
- 1500VA UPS 1050watts input and output power, 10 minute battery at 90% load
- - Weight 59 lbs. tested and approved standalone, WITH 6 MIL CONNECTORS, no Isolation Transformer
- Input and output CORCOM EMI/RFI filtering for mil 461
- Shipboard and/or global GLUPS™ Mil 1399 delta Power, military ruggedized stainless steel chassis (stainless 304)
- Mil 5015 MS3102 threaded connectors or 4ea. 5-15 standard outlets ( option to 6ea. 5-15 outlets)
- New- Now it comes standard with a stainless steel chassis and option to add Isolation transformer later- made in USA stainless steel chassis or order the PS1503 as a floormount unit (Bulkhead mounting)
- - add Modular design deliverable with/without ISO, dual pole (mil 1399) delta power, modular backplates
- - Intelligent UPS, built-in self test, individual battery test, hot start, relay self test, online voltage adjustments on/the/fly™
- - add Front or rear mounted Dual pole circuit breaker, on/off reset for shipboard, emergency power off /power on™
- - add 1 inch for mil ms3102 connectors
- - add Intelligent ruggedized packaging, metal battery tie-down, wire tieback, shock mounted motherboard, color coded wire
- - Coated heat resistant, shock resistant connectors added
- - UPS shutdown software available for UNIX, HP, SUN, SCO, Novell , NT, Apache Web, called Powerchute +
- - 96% efficiency at full load
- Ruggedized motherboard, single board construction
- - Maximum current 17.5 amps double pole toggle hi-shock input breaker, and output breakers mounted on front or rear
- -add 100 based T Ethernet or fiber interface
- - RS232 communication built in, optional Expansion bus in module for 3 RS232 (three computers),
- - Front Panel bolted down for safety, FAA CFR 49 approved for shipping(non-hazardous), sealed maintenance free batteries
- optional 140degree F hi-temp 10 year battery life batteries
- - quick release front panel battery removal, online test from front panel
- - Powerful MOV surge and spike firewall protection, isolates racks from spikes up to 400 joules- UL 1778
- - Voltage range from 137 volts to 85 volts 47-63 HZ. for global usage, without going to battery with sensitivity settings
- - Battery disconnect from back for shipping and emergencies without opening case (extends storage life of batteries)
- - Extensive self maintenance manual, and user manual included
- - Software provided Powerchute +
- - Two year limited warranty
- - Spares stocked by NAVICP
- Thermal dissipation on line fully charged 40w/ 135 BTU Charging 70 watts / 240 BTU
- cage code 0zap8 Thousands installed
-
